Bianco BIA-FC300T Cast Iron Small Centrifugal Pump 415V
The pumps are horizontal single stage* cast iron centrifugal pumps supplied ready to install. Used especially for water transfer. (*FCT is twin stage).
Technical Specifications
| Brand | Bianco Pumpz |
| Product Type | Single Stage Cast Iron Centrifugal Pump |
| Suitable For | Clean Water |
| Bar | 3.8 Bar |
| Amps | 8.2 Amps |
| Flow Range Category | e. 400 – 499 L/min |
| Flow Rate (L/min) | 450 L/min |
| Hp | 4.0 Hp |
| Kilo Watts | 3.0 kW |
| Head Range Category | a. 0 – 39 m |
| Max Head (m) | 38 m |
| Port Size Inlet | 2″ Inlet |
| Port Size Outlet | 2″ Outlet |
| Powered | Electric |
| Volts | 415 V |
| Warranty (months) | 24 Months |
Pack Weight (KG): 42
The pumps are characterised by:
- Corrosion resistant cast iron pump body and bracket cover with cataphoresis1 treatment, and 304 stainless steel impeller and shaft.
- Mechanical shaft seal.
- TEFC motors.
- Motor support foot
Applications:
- Suitable for industrial wash down, water transfer and tank filling. Suitable for fire fighting, HVAC, circulation and pressure boostin
