DAB 82MP Cast Iron Surface Mounted Jet Pump with Pressure Switch (701445)
The DAB82MP is a pressure switch controlled cast iron, self-priming centrifugal pressure pump with excellent suction capacity even when there are air bubbles in the water.
Particularly suited to water supply in domestic installations, small-scale agriculture, gardening and wherever self- priming operation is required.
DAB Jet pumps are renowned for their unique self priming and extraordinary deep suction capability; up to 8 metres at sea level.
*Pressure tank is required to operate – sold separately.
Technical Specifications
| Brand | DAB Pumps |
| Product Type | Pressure System |
| Suitable For | Clean Water |
| Bar | 4.7 Bar |
| Approval | Approved For Drinking Water |
| Flow Range Category | a. 0 – 99 L/min |
| Flow Rate (L/min) | 60 L/min |
| Hp | 0.8 Hp |
| kPa | 476 kPa |
| Kilo Watts | 0.6 kW |
| Head Range Category | b. 40 – 59 m |
| Max Head (m) | 47 m |
| Port Size Inlet | 1″ BSPF inlet |
| Port Size Outlet | 1″ BSPF outlet |
| Powered | Electric |
| Taps | 6 Taps |
| Warranty (months) | 24 Months |
| Volts | 240 V |
| Watts | 600 W |
Applications
• Household water supply – small to medium dwellings
• Light garden irrigation
• Water transfer
• Washing systems
• Pressure boosting
Features
Motor support in cast iron, technopolymer impeller, diffuser, Venturi tube and sand guard. Stainless steel
adjustment rings.
• Carbon/ceramic mechanical seal.
• Asynchronous motor closed and cooled by external ventilation. Max Ambient temp 40 deg C
• Built-in thermal and current overload protection and a capacitor permanently on in the single-phase versions.
Weight: 12.1KG
Drinking Water Approved
AS/NZS 4020 Drinking Water Approved.
Made in Italy
