DAB FEKA BVP750MA Submersible Vortex


Product Documents

SKU: BVP750MA Categories: ,

DAB FEKA BVP750MA Vortex Submersible Drainage Pump

Designed for pumping foul water containing soft solid particles up to 38mm and made with anti corrosion and anti oxidation materials. The motor has a thermal protection against overheating, and includes a wear resistant motor shaft and impeller. There is excellent motor cooling to allow the pump to run even when only partially submerged. The DAB-BVP750MA is equipped with a float switch for automatic starting and stopping of the pump and plug and play power cable.

DAB Pumps include a two year parts and labour warranty

Technical Specifications
Brand DAB Pumps
Product Type Vortex Pump
Suitable For Dirty Water
Bar 1.14 Bar
Flow Range Category e. 400 – 499 L/min
Flow Rate (L/min) 400 L/min
Hp 1 Hp
Kilo Watts 0.75 kW
Head Range Category a. 0 – 39 m
Max Head (m) 11.4 m
Port Size Outlet 1 1/2″ BSPF outlet
Powered Electric
Particle Size 38 mm
Warranty (months) 24 Months
Volts 240 V
Watts 750 W
Weight 9 kg
Dimensions 25 × 25 × 45 cm
