DAB EUROINOX40/50MP Pressure Switch Pump

$765.00

Product Documents

Availability: In stock

None 25mm Brass Y-Strainer +$25.00 32mm Brass Y-Strainer +$35.00 40mm Brass Y-Strainer +$50.00 50mm Brass Y-Strainer +$75.00
SKU: DAB-EUROINOX40/50MP Categories: , GTIN: 8019203534375

DAB EUROINOX 40/50MP Pressure Switch Pump

Euroinox Stainless Steel Self Priming Horizontal Multistage Pumps. Fully adjustable pressure switch to reduce pressure fluctuations. Stainless steel pump body for bacteria and corrosion resistance. Brass non return valve and fittings for strength and durability. Replaceable TEFC motor with air gap to stop seal failure water entry.  2 year pump parts & labour warranty.

Note: EUROINOX pumps are AS/NZS4020 approved for drinking water.

Technical Specifications
Brand DAB Pumps
Product Type Pressure System
Suitable For Clean Water
Bar 5.77 Bar
Approval Approved For Drinking Water
Flow Range Category a. 0 – 99 L/min
Flow Rate (L/min) 80 L/min
Hp 1.1 Hp
kPa 585 kPa
Kilo Watts 0.8 kW
Head Range Category b. 40 – 59 m
Max Head (m) 57.7 m
Port Size Inlet 1″ BSPF inlet
Port Size Outlet 1″ BSPF outlet
Powered Electric
Taps 8 Taps
Warranty (months) 24 Months
Volts 240 V
Watts 800 W



Weight 13 kg
Dimensions 50 × 28 × 35 cm
Product Type

Pressure System

Suitable For

Clean Water

Bar

5.77 Bar

Approval

Approved For Drinking Water

Flow Range Category

a. 0 – 99 L/min

Flow Rate (LT/min)

80LT/min

Hp

1.1 Hp

kPa

585 kPa

Kilo Watts

0.8 kW

Head Range Category

b. 40 – 59 m

Head (max)

57.7m

Port Size Inlet

1" BSPF inlet

Powered

Electric

Taps

8 taps

Volts

240 V

Warranty

24 Months

Watts

800 W

Pack Weight

12.00 KG

Brand

DAB Pumps
