DAB EUROINOX40/80M Multistage Stainless Pump

$850.00

SKU: DAB-EUROINOX40/80M Categories: ,

Product Documents

DAB EUROINOX 40/80M Multistage Stainless Steel  Pump

Euroinox Stainless Steel Self Priming Horizontal Multistage Pumps. Stainless steel pump body for bacteria and corrosion resistance. Brass non return valve and fittings for strength and durability. Replaceable TEFC motor with air gap to stop seal failure water entry.  2 year pump parts & labour warranty.

Note: EUROINOX pumps are AS/NZS4020 approved for drinking water.

Technical Specifications
BrandDAB Pumps
Product TypeHorizontal Multistage Pump
Suitable ForClean Water
Bar5.9 Bar
ApprovalApproved For Drinking Water
Flow Range Categoryb. 100 – 199 L/min
Flow Rate (L/min)120 L/min
Hp1.36 Hp
kPa598 kPa
Kilo Watts1 kW
Head Range Categoryb. 40 – 59 m
Max Head (m)59 m
Port Size Inlet1″ BSPF inlet
Port Size Outlet1″ BSPF outlet
PoweredElectric
Warranty (months)24 Months
Volts240 V
Watts1000 W

Brand

DAB

dab logo
Product Type

Horizontal Multistage Pump

Suitable For

Clean Water

Bar

5.9 Bar

Approval

Approved for Drinking Water

Flow Range Category

b. 100 – 199 L/min

Flow Rate (LT/min)

120LT/min

Hp

1.36 Hp

kPa

598 kPa

Kilo Watts

1 kW

Head Range Category

b. 40 – 59 m

Head (max)

59m

Port Size Inlet

1" BSPF inlet

Powered

Electric

Warranty

24 Months

Volts

240 V

Pack Weight

15.10 KG
