DAB-JETCOM132CORE Pressure Pump with nXt Pump Controller 808415
DAB jet pumps are renowned for their unique self priming and extraordinary deep suction capability: up to 9 metres at sea level. They are designed to handle abrasive and corrosive water which makes them ideally suited for spear point applications. 2 year pump parts & labour warranty.
- Automatically restarts after water loss or interrupted power.
- Dry run protection protects pump from damage
- Eliminates water hammer protecting plumbing
- Compact size for easier installation
- Taps: 8
- Weight: 12KG
- Designed in Italy
*Fitment of a 3, 8 or 18 litre pressure vessel is encouraged to reduce pump starts and save energy – sold separately
| Brand | DAB Pumps |
| Product Type | Pressure System |
| Suitable For | Clean Water |
| Bar | 4.7 Bar |
| Approval | Approved For Drinking Water |
| Flow Range Category | a. 0 – 99 L/min |
| Flow Rate (L/min) | 80 L/min |
| Hp | 1.36 Hp |
| kPa | 470 kPa |
| Kilo Watts | 1 kW |
| Head Range Category | b. 40 – 59 m |
| Max Head (m) | 48 m |
| Port Size Inlet | 1″ BSPF inlet |
| Port Size Outlet | 1″ BSPM outlet |
| Powered | Electric |
| Taps | 8 Taps |
| Volts | 240 V |
| Warranty (months) | 24 Months |
| Watts | 1000 W |
Controller
This pump includes the Bianco iCON nXt series of pump controller.
The nXt Controller is designed and tested in Australia to ensure operation in the toughest of environments, combining innovative technology with robust proven architecture to guarantee constant supply of pressurised water when and where you need it the most.
Controller Features
- Digital display gives you a real time indication of system pressure
- Anti-cycle Protection
- Dry run protection with auto restart function that tests for water availability every 24hrs
- Anti-seize function if pump has not operated for last 24 hours
- Controller automatically restarts pump after a power failure
- Easy assembly and removal using push-n-connect fitting with U clip
- Complies to AS/NZ 4020 drinking water standard
- Over pressure protection turns pump off when 10 bar is reached
- Overload protection
