DAB JINOX132M Self Priming Electronic Stainless Steel Spear Point Pump (701591)
Self priming stainless steel jet pumps. DAB jet pumps are renowned for their unique self priming and extraordinary deep suction capability: up to 9 metres at sea level. They are designed to handle high performance applications and are Corrosion resistant. Self priming for long and difficult suction applications. Electronic pump control with dry run protection and auto restart. Suitable for tanks, dams and creeks. 2 year pump parts & labour warranty.
Features & Benefits
- AS/NZS 4020 Approved for drinking water.
- Automatically restarts after water loss or interrupted power.
- Dry run protection protects pump from damage
- Eliminates water hammer protecting plumbing
- Compact size for easier installation
- 2 Year Warranty
Weight: 11KG
Applications
- Household water supply – large dwellings
- Light garden irrigation
- Water transfer
- Washing systems
- Pressure boosting
Technical Specifications
| Brand | DAB Pumps |
| Product Type | Pressure System |
| Suitable For | Clean Water |
| Bar | 4.8 Bar |
| Approval | Approved For Drinking Water |
| Flow Range Category | a. 0 – 99 L/min |
| Flow Rate (L/min) | 80 L/min |
| Hp | 1.36 Hp |
| kPa | 486 kPa |
| Kilo Watts | 1 kW |
| Head Range Category | b. 40 – 59 m |
| Max Head (m) | 48 m |
| Port Size Inlet | 1″ BSPF inlet |
| Port Size Outlet | 1″ BSPM outlet |
| Powered | Electric |
| Taps | 8 Taps |
| Warranty (months) | 24 Months |
| Volts | 240 V |
| Watts | 1000 W |
Construction Materials of the Pump
- Cast iron pump body and motor support.
- Motor support in die-cast aluminium for Jet 62-82-102-112-92-132.
- Technopolymer impeller, diffuser, Venturi tube and sand guard.
- Stainless steel pressure discs.
- Carbon/ceramic mechanical seal.
Drinking Water Approved
AS/NZS 4020 Drinking Water Approved.
Pumps that are AS/NZS 4020 Drinking Water Approved Offer peace-of-mind.
This approval ensures that the pump will not contribute any toxic materials or metals to the liquid being pumped, won’t support the growth of micro-organisms and won’t change the taste or appearance of your water.
