Grundfos SCALA1 3-45 Self Priming Pressure Booster

$625.00

Product Documents

Availability: In stock

None Twin Installation Kit +$850.00
SKU: SCALA1 3-45 Categories: , , Tags: , GTIN: 5713830592540

Grundfos SCALA1 3-45 Self Priming Booster Pump 99530420

The SCALA1, all-in-one, self-priming domestic pressure booster range makes it easy to take control and get pumping. Using the Grundfos Go App (which is available to download on Android and Apple Devices) you can access the advanced features of SCALA1 and further customize and control the pump’s functions.

Whether it’s being able to turn the pump on and off remotely, set a schedule for watering the garden to save power and water, or monitoring and re-setting alarms, the Grundfos Go App puts pump control at your fingertips.

  • For water sources below pump level – Designed with good suction lift capabilities, the SCALA1 is able to draw water up to 8 metres vertically below the level of the pump
  • Quiet operation – Super quiet operation that won’t disturb your family or neighbours
  • All-in-one construction – Tough, weather resistant outer casing houses the pump, motor and the controller
  • Easy installation – plug & pump – Simply connect the pump inlet and outlet to the pipework, prime the pump, plug into a power outlet and you’re ready to pump
  • Simple to operate and monitor – Seamlessly connect to your SCALA1 using the Bluetooth connected Grundfos GO App.
  • Twin Booster – For higher flow demand SCALA1 can be easily be setup as a twin booster. Duty assist and duty standby modes available. Base plate, manifolds, communication cable and fixing screws available as an accessory kit.

Motor / power (P2): 580W
Max. flow:
60LT/min
Head:
44m
Inlet:
1″M / 25mm
Outlet:
1″M / 25mm
Pressure:
440kPa
Impeller:
Composite
Warranty on pump: 2 Years
Ambient Temperature: 0°C to +55°C
Liquid Temperature: 0°C to +45°C
System Pressure: Max. 8 bar
System Inlet Pressure: Max. 3 bar
Sound Pressure: Max. 55dB
Power Supply Voltage: 230V 50Hz
Power Supply Cable: 1.5m with plug
Enclosure Class: Suitable for outdoor installation (IPX4D)
Approvals and Markings: AS/NZS 4020, C-Tick Compliance
Code:
99530420









Weight 14 kg
Dimensions 54 × 24 × 35 cm

Brand

Grundfos Pumps

ASC is the largest stockist of Grundfos Domestic Building Products. This includes the famous Grundfos CMB and JET range of domestic water pumps, submersible pumps, waste water pumps, drainage pumps and variable speed pumps. Grundfos Pumps are world renowned pump manufactures, and deliver pumps to over 80 countries world-wide. Grundfos Australia PTY LTD is part of this global network delivering pump expertise and innovation. Whilst initially established to support mining and agricultural sectors, the demand for good quality pumps at a domestic level saw Grundfos bring it's range to Australia. Since 1980, Grundfos Pumps has grown across to five states, bringing one of the most comprehensive range of pumps to the Australian market. Grundfos stands behind all of our products and all of our customers – from farmers who need reliable water in remote paddocks, to miners who need constant supply and pressure to maintain production, to the residents of houses, offices and apartments all over Australia, who’ve come to enjoy a clean and steady water supply as a part of their everyday lives. Grundfos expertise
  • Pumps and Motors
  • Submersible pumps
  • Single stage pumps (end suction, inline and splitcase)
  • Multistage pumps
  • Wastewater pumps
  • Solar and wind powered systems
  • Fire pumps
  • Mixers, flow makers, aerators and ejectors
  • Domestic boosters
  • Boosting pumps and systems
  • De-watering and drainage pumps
  • Dosing and disinfectant pumps
  • Controls and Monitoring
  • Accessories
