Grundfos SCALA1 3-45 Self Priming Pressure Booster


Product Documents

Availability: In stock

None Twin Installation Kit +$850.00
SKU: SCALA1 3-45 Categories: , , Tags: , GTIN: 5713830592540

Grundfos SCALA1 3-45 Self Priming Booster Pump 99530420

The SCALA1, all-in-one, self-priming domestic pressure booster range makes it easy to take control and get pumping. Using the Grundfos Go App (which is available to download on Android and Apple Devices) you can access the advanced features of SCALA1 and further customize and control the pump’s functions.

Whether it’s being able to turn the pump on and off remotely, set a schedule for watering the garden to save power and water, or monitoring and re-setting alarms, the Grundfos Go App puts pump control at your fingertips.

  • For water sources below pump level – Designed with good suction lift capabilities, the SCALA1 is able to draw water up to 8 metres vertically below the level of the pump
  • Quiet operation – Super quiet operation that won’t disturb your family or neighbours
  • All-in-one construction – Tough, weather resistant outer casing houses the pump, motor and the controller
  • Easy installation – plug & pump – Simply connect the pump inlet and outlet to the pipework, prime the pump, plug into a power outlet and you’re ready to pump
  • Simple to operate and monitor – Seamlessly connect to your SCALA1 using the Bluetooth connected Grundfos GO App.
  • Twin Booster – For higher flow demand SCALA1 can be easily be setup as a twin booster. Duty assist and duty standby modes available. Base plate, manifolds, communication cable and fixing screws available as an accessory kit.

Motor / power (P2): 580W
Max. flow:
1″M / 25mm
1″M / 25mm
Warranty on pump: 2 Years
Ambient Temperature: 0°C to +55°C
Liquid Temperature: 0°C to +45°C
System Pressure: Max. 8 bar
System Inlet Pressure: Max. 3 bar
Sound Pressure: Max. 55dB
Power Supply Voltage: 230V 50Hz
Power Supply Cable: 1.5m with plug
Enclosure Class: Suitable for outdoor installation (IPX4D)
Approvals and Markings: AS/NZS 4020, C-Tick Compliance





Weight 14 kg
Dimensions 54 × 24 × 35 cm
